4ms SCMBO (Shuffling Clock Multiplier Breakout)

Article number: CV0502
$150.00
Total

Expands functionality of SCM (Shuffling Clock Multiplier)

The rating of this product is 0 out of 5

(0)
Available Immediately

Expands functionality of SMC (Shuffling Clock Multiplier). Connects to SCM with a standard 16-16 pin cable.

Features
• CV Shuffle jack and knob selects which beats are slipped by CV Slip (default=every other beat)
• CV Pulse Width jack and knob controls width of output pulses (default=50%)
• CV Skip jack and knob omits certain beats in a pattern (default=no skip)
• Re-sync Trigger input
• Additional CV Rotate and CV Slip jacks add to main SCM's Rotate and Slip jacks
• 4x Fast CV Gate jack and switch speeds up multiply-by amounts
• Mute CV Gate jack and switch stops any more beats from starting

Inputs
• Resync

Controls with CV Inputs
• Rotate
• Slip
• Shuffle
• Skip
• PW
• 4x Fast
• Mute

<

In the Box
• The module itself
• Eurorack Power Cable, 16-16-pin

+12v 14mA
-12v 0mA
+5v 0mA
Width 8HP
Depth 26mm
