This item is used, has been fully tested and is guaranteed to be working. MOSFET 24dB/Octave Low Pass Filter

POLE-ZERO is a 4-pole (24dB/octave) low pass Voltage Controlled Filter (VCF) utilizing MOSFET transistors. MOSFETs are known for their soft, vacuum tube like distortion when overdriven. POLE-ZERO is designed to exploit these characteristics with the addition of a MOSFET saturation control and provide a much wider palette of sounds when compared to a standard VCF. A Voltage Controlled Amplifier (VCA) is also a relatively novel addition and provides a simple way to amplitude modulate the filter without the need of an external VCA.

Features
• 4-pole (24dB/octave) low pass filter
• Resonance up to self oscillation
• 1V/octave CV input
• Dedicated FM input with polarizing attenuator
• Mosfet saturation adds warmth and low end punch
• Integrated VCA with CV input

Inputs
• Audio
• FM
• 1V/Oct
• Amp CV

Outputs
• Audio

Controls
• Cutoff
• Resonance
• FM Level
• Saturation

In the Box
• The module itself
• Eurorack Power Cable
