KOMA STROM+ Bundle

The KOMA STROM+ Bundle is a great and cost effective power solution for your Eurorack case. The Bundle pack includes a high-quality CINCON adapter, STROM+ power module and a flying bus board. STROM + offers a current sensing technology so you have your consumption under control at all times!

STROM Module
• Input: 15 V DC, 4.6 A (center positive)
• Output: 1,5A @ +12V / 1,5A @ +5V / 1,0 A @ -12V

Current Sensing Technology
• The status LED's on the module will turn orange and red when you approach the maximum amount of current on your rails.

Connectors and Controls
• Main DC-Input (15 VDC)
• On/Off Switch
• Front Panel Link-Connector to a passive module
• 2 Standard EurorackPower Connectors (connect modules or a flying busboard)
• Back Panel Link Connector To Solid Busboards

CINCON AC/DC Adapter
• Input Voltage: 90 VAC to 264 VAC
• Output Voltage-Channel 1: 15 V
• Output Current-Channel 1: 4.65 A
• DC Output Connector: 2.5 mm Barrel Plug
• DC Output Lead Length: 1.22 m

Features
• Replaceable Fuse
• Short-Circuit Protection for Each Rail (+12V, +5V and -12V)
• Very Low Ripple on Each Rail, Also Under Full Load!
• 7 Standard Eurorack Power Connectors (connect modules)

Physical Specifications
• Format: Eurorack
• Width: 4hp
• Depth: 50mm
