Features
• 12 bit USB-to-MIDI-to-CV converter module with 16 arbitrary assignable channels
• simultaneous USB on-the-go device and host modes using 120 MHz 32-bit ARM Cortex™-M3 CPU
• internal PSU capable of working from cigarette lighter receptacle, rechargeable battery or 12-20V AC-DC power adapter
• no drivers are required for a direct connection to your MAC/PC or iOS devices
• up to 8 voices of polyphony, polyphonic key aftertouch, no steps in CC voltages, MIDI clock, Tap Clock, Tap LFO, bi-directional USB-MIDI transfer and many more MIDI events can be translated into CV
Shuttle Control consists of the following parts:
• Switched mode PSU
• USB-to-MIDI-to-CV converter
• Web-based editor for editing presets
In the Box
• The module itself
• Eurorack Power Cable w/5 16pin connectors
• USB Cable, keychain & screws
+12v | 200mA |
---|---|
-12v | 100mA |
+5v | 0mA |
Width | 12HP |
Depth | 35mm |
